Product Spotlight

peel 3d Scanner

Accurate handheld 3D scanner for fast and easy data collection. A next-generation companion to Verisurf software for digitizing/reverse engineering & high volume pointcloud inspection.

KEY BENEFITS

The peel 3 scanner is fast and extremely easy to use, offering a scan speed of up to 80 sec/m2 (7.4 sec/ft.2) with an accuracy of up to 0.1 mm (0.004 in).

With this rugged handheld 3D scanner, you can tackle complex projects and take advantage of higher measurement resolution, color capture, enhanced tracking, and enhanced geometry capture.

The 3D handheld laser scanner works seamlessly with Verisurf in a single, integrated workflow. Bundle the scanner with several different Verisurf Scan Data software suite configurations depending on your usage requirements or coordinate with your Verisurf representative to define a software configuration that best suits your unique situation.

Fast, easy plug and play 3D SCAN-TO-CAD with Verisurf Software connect integration.

Complete reverse engineering solution for complex applications such as automotive aftermarket, clay model sculpture capture and biomedical prosthetics.

Powerful mesh editing and solid modeling with optional “Quick Surface” class A surfacing. Click for details on Quick Surface.

Complete 3D Scanning and

Reverse Engineering Solution

Everything you need to efficiently perform common 3D scanning and reverse engineering tasks using high-quality, handheld scanning hardware – seamlessly integrated with Verisurf’s industry-leading Scan Data and Reverse Engineering Suite.

3D Metrology Software, Training and CMMspeel 3 Scanner

peel 3 Scanner Applications

Scan Data Reverse Engineering

The combination or your peel 3 scanner and the Verisurf Scan Data Reverse Engineering Suite is the right toolset for any 3D reverse engineering project that begins with importing pointcloud or mesh scan data.  The suite features an extensive set of tools for managing, merging, hole filling, smoothing, filtering, meshing, and surfacing both pointcloud and mesh data. Because all Verisurf solutions are CAD-based, the suite also includes an extensive set of tools for completing a clean, smooth and water-tight, printable STL file or a full-featured solid model with NURBS surfaces, wireframe/sketching, parametric modeling, detailed drawings and intelligent GD&T.

Also available Quick Surface option for advanced, high-quality surfacing from meshes.

3D Metrology Software, Training and CMMspeel 3 Scanner

Inspection

Pair your peel 3 scanner with the Verisurf Scan Data Inspection Suite. This combination of scanner hardware and software integrates Verisurf’s CAD and ANALYSIS modules to tackle inspection challenges using imported pointcloud data. Easily import scan data collected with your peel 3 scanner to automatically analyze, extract, and compare features to CAD nominal with intelligent GD&T. Save reusable, automated inspection plans to support high-volume production.

Scan Data Suite

The peel 3 scanner paired with the Verisurf Scan Data Suite offers the ultimate flexibility to support both scan data reverse engineering and inspection workflows.

3D Metrology Software, Training and CMMspeel 3 Scanner
3D Metrology Software, Training and CMMspeel 3 Scanner

Metrology Education

The Metrology Education Suite for educational institutions includes all Verisurf modules at pricing considerably less than commercial levels. Exclusively for the needs of technical educators and their students, the Metrology Education Suite presents students with the opportunity to develop the metrology skills employers seek.

The Verisurf Metrology Education Suite is a premium software bundle suitable for performing a broad spectrum of metrology tasks, making it the perfect companion for a 3D color scanner. It is the logical next step to extending popular CAD/CAM training programs to include reverse engineering, tool building, and inspection skills development.  Import all common 3D geometry file types, connect to any available scanner, fixed or portable measuring device, or work offline with imported point cloud or mesh files. Can be used for both scan- and probe-based inspection, tool-building, reverse engineering, CMM programming, guided assembly, and more. The Verisurf Metrology Education Suite has it all.

3D Metrology Software, Training and CMMspeel 3 Scanner

peel 3 Scanner Specifications

Recommended object size 0.1-3.0 mm (0.004-0.118 in.)
Accuracy 0.250 mm/m, up to 0.1 mm (0.004 in.)
Scan speed 80 sec/m2 (7.4 sec/ft.2)
Usage distance (from object) 250 to 550 mm (9.8 to 21.6 in.)
Projector light source IR VCSEL
Scanner controls Touchscreen
Color resolution (on object) 250 DPI
Dimensions 304 x 150 x 79 mm (12.0 x 5.9 x 3.1 in.)
Weight 950 g (2.1 lbs.)
Connectivity USB 3.0

peel 3d Setup

Install and Configuration

peel 3d Scanner
