Features Overview

KEY BENEFITS

Verisurf VALIDATE is for aerospace part suppliers with DPD/MBD process requirements. It provides precise CAD model translation validation by comparing the authority CAD model to the translated CAD model, enabling manufacturers to quickly identify any translation error. Verisurf VALIDATE helps reduce scrap and rework from bad CAD translations and complies with Boeing D6-51991 “Quality Assurance Standard for Digital Product Definition”.

3D Metrology Software, Training and CMMsValidate
Translates all major file formats and meets all aerospace industry CAD data validation and documentation requirements.
3D Metrology Software, Training and CMMsValidate
Pattern matching comparison method provides objective evidence validating the translation process.
3D Metrology Software, Training and CMMsValidate
Powered by independent, CAD-neutral 3D framework with multi-threaded architecture that delivers unmatched speed and performance.

KUBOTEK KOSMOS VALIDATE Standard
Includes the following functions.

Advanced Geometric Comparison

3D Metrology Software, Training and CMMsValidate

Face-to-face geometric pattern matching analyzes the whole part definition within the user controlled tolerance. This strategy reliably finds the differences across all precise CAD models without the common failures and false positives of the Boolean approach, or missed areas inherent with the sampling of points approach.

Boeing D6-51991 Compliance

3D Metrology Software, Training and CMMsValidate

Boeings quality system requirement for Aerospace suppliers with sections that require translated CAD data to be validated for quality system compliance.

Distance Measurements

3D Metrology Software, Training and CMMsValidate

Measure the distance between entities, points, and positions and angles between two edges or faces, or 4 positions.

Assembly
Comparison

3D Metrology Software, Training and CMMsValidate

A special mode for two sets of hierarchical CAD assembly files scans file names and headers and lists side-by-side results. Users can optionally geometrically compare a selected set of parts or launch processes to compare all parts. Quick side-by-side 3D graphical viewing is available to see differences in impacted parts.

Selective
Comparison

3D Metrology Software, Training and CMMsValidate

When the authority or derivative files have extra data that is inconsequential to validation, a selective compare can be accomplished by choosing the data from each file for comparison.

Re-Orientation of Derivative

3D Metrology Software, Training and CMMsValidate

When the derivative data is in a different orientation than the authority data (typically for manufacturing setups), the derivative can be automatically or manually oriented to match the authority data before comparison.

Non-Solid Derivative Files

3D Metrology Software, Training and CMMsValidate

When the software that is receiving a solid model of the design data can not output a solid model (some metrology software) the translation of the authority data is validated by outputting a point cloud that represents the measured points on the data. This point data is compared to the authority solid and surface data to perform the validation.

A similar approach is used to compare mesh data in STL derivative files to the precise authority data set (Premium level only).

PMI
Annotations

3D Metrology Software, Training and CMMsValidate

Compare semantic differences in Product Manufacturing Information (PMI) including 3D geometric tolerances from these formats:

Dassault CATIA

PTC Creo

Siemens NX

Dassault SolidWorks

STEP AP 242

Optional Network
License

3D Metrology Software, Training and CMMsValidate

Benefits of network floating licenses:

  • Access software from multiple devices and locations.
  • Unlimited number of users.
  • More flexible and dynamic software usage.
  • Shared software can result in significant savings.

Example of two concurrent users of network floating licenses managed from network license server.

STEP

3D Metrology Software, Training and CMMsValidate

STEP, STP, STPZ

IGES

3D Metrology Software, Training and CMMsValidate

IGES, IGS

Dassault CATIA V5

3D Metrology Software, Training and CMMsValidate

CATPart, CATProduct

SolidWorks

3D Metrology Software, Training and CMMsValidate

SLDPRT, SLDASM

Siemens NX

3D Metrology Software, Training and CMMsValidate

PRT

Siemens JT

3D Metrology Software, Training and CMMsValidate

JT

PTC Creo

3D Metrology Software, Training and CMMsValidate

PRT, ASM

KUBOTEK KOSMOS VALIDATE Premium
Including all the functions of Standard plus the following.

Batch Comparison

3D Metrology Software, Training and CMMsValidate

Sets of authority and derivative files can be batch processed through the user interface or executed from the command line.

Error Dispositioning

3D Metrology Software, Training and CMMsValidate

Inconsequential errors found as a result of compare can be quickly dispositioned with a short text explanation and documented in the output quality document.

Validation Traceability

3D Metrology Software, Training and CMMsValidate

Quality documents include built-in features that provide traceability back to the original validation to meet audit requirements.

Captures

3D Metrology Software, Training and CMMsValidate

Images of differences can be automatically included in the output quality document.

Certified Quality Document (Text)

3D Metrology Software, Training and CMMsValidate

Comparison results recorded as certified, tamper-proof ASCII text documents customized with your company name.

Certified Quality Document (PDF)

3D Metrology Software, Training and CMMsValidate

Comparison results recorded as certified, tamper-proof PDF documents customized with your company name.

Sandvik Mastercam

3D Metrology Software, Training and CMMsValidate

MCX

Dassault CATIA V4

3D Metrology Software, Training and CMMsValidate

MOD

Dassault CATIA V6

3D Metrology Software, Training and CMMsValidate

3DXML

Autodesk Inventor

3D Metrology Software, Training and CMMsValidate

IPT, IAM

Kubotek KeyCreator

3D Metrology Software, Training and CMMsValidate

CKD

Siemens Solid Edge

3D Metrology Software, Training and CMMsValidate

PAR, ASM, PSM

Siemens
Parasolid

3D Metrology Software, Training and CMMsValidate

X_T, X_B

Dassault (Spatial Corp.) ACIS

3D Metrology Software, Training and CMMsValidate

SAT, SAB

AutoDesk
DXF & DWG

3D Metrology Software, Training and CMMsValidate

DWG, DXF

3D Metrology Software, Training and CMMsValidate

CAD Translation Validation for Manufacturing

LEARN MORE

Complete Aerospace Inspection With CAD Validation Package

3D Metrology Software, Training and CMMsValidate

VALIDATE
