| Measure Hotkeys – Measure Settings active, Graphical window has focus. |
| Key |
Function |
Description |
| 1 |
Points |
Initiates Point measurement. |
| 2 |
Lines |
Initiates Line measurement. |
| 3 |
Circles |
Initiates Circle measurement. |
| 4 |
Planes |
Initiates Line measurement. |
| 5 |
Spheres |
Initiates Sphere measurement. |
| 6 |
Cylinders |
Initiates Cylinder measurement. |
| 7 |
Cones |
Initiates Cone measurement. |
| 8 |
Slots |
Initiates Slot measurement. |
| 9 |
Ellipses |
Initiates Ellipse measurement. |
| 0 |
Inspect |
Initiates Inspect/Build mode. |
| A |
Arrows |
Toggles Build Arrow display On/Off while Inspect/Build. |
| B |
Ball |
Toggles On/Off to display measured points as spheres. |
| C |
Center |
Center the Graphics window on the current probe location. |
| D |
Done |
Terminate the measurement of the current feature. |
| G |
Color bar |
Toggle color bar gage. |
| K |
Skip |
Use during Auto Alignment and Auto Inspect. |
| L |
Laser beam |
Toggles Laser Beam display, from the origin of the active device to the measure Points. |
| M |
Projection |
Opens Preferences – Projection Settings. |
| N |
Name |
Toggles Point names On/Off. |
| P |
Mode |
Toggle between Single/Stationary Point and Continuous Pointcloud. |
| R |
Device DRO readout |
Toggles Device Manager display on/off. |
| S |
Settings |
Toggle to hide or unhide Measure Settings dialog. |
| U |
Undo |
Undo the last probe-hit or when measuring features, undo the feature. Works when using Measure and Auto Align. |
| V |
Vectors |
Toggles Feature and Point vectors on/off and small, mid, or large. |
| [+] |
Inc |
Increment the Point number. |
| [-] |
Dec |
Decrease the Point number. |
| ESC |
Finish/Abort |
Finish or Abort current Feature measurement. |
| Spacebar |
Measure |
Trigger measurements. |
|
| Operations Managers Hotkeys – Operations Manager, has focus. |
| Key |
Function |
Description |
| B |
Ball display |
Toggles on/off to display measured points as spheres. |
| D |
Feature display |
Toggle Feature body display. |
| G |
Alignment |
Global Register. |
| L |
Laser beam |
Toggles Laser Beam display, from the origin of the active device to the measure Points. |
| N |
Name |
Toggles point names on/off. |
| R |
Device DRO readout |
Toggles Device Manager on/off. |
| S |
Measured features |
Show feature measured points |
| V |
Vectors |
Toggles Feature and Point vectors On/Off. |
| Z |
Vector size |
Toggles the Vector of the Point or Feature; off, small, medium, or large. |
|
| Device Hotkeys |
| Button |
Function |
Description |
| First |
Trigger |
Record a probe-hit. |
| Second |
Done |
Terminate measurement of the current feature. |
| Second+hold |
Undo |
Undo the last probe-hit or, when measuring features, undo the feature. |
| F8 |
Home |
For Laser Trackers only. |
|
| Mastercam Hotkeys |
| Key |
Function |
Description |
| Spacebar |
Repeat |
Repeats previous command. |
| Alt + 1 |
GView – Top |
Top Graphics view. |
| Alt + 2 |
GView – Front |
Front Graphics view. |
| Alt + 3 |
GView – Back |
Back Graphics view. |
| Alt + 4 |
GView – Bottom |
Bottom Graphics view. |
| Alt +5 |
GView – Right |
Right Graphics view. |
| Alt +6 |
GView – Left |
Left Graphics view. |
| Alt + 7 |
GView – Isometric |
Isometric Graphics view. |
| Alt + Arrow Keys |
Rotate |
Rotate view. |
| Alt + C |
Run Add-In |
Run C-hooks. |
| Alt + D |
Drafting Options |
Opens Drafting Options. |
| Alt + E |
Hide / Unhide |
Hides / Unhides selected CAD entities. |
| Alt + F1 |
Fit |
Fit model to Graphics window. |
| Alt + F2 |
Unzoom 80% |
Unzoom view by 80%. |
| Alt + F4 |
Exit Mastercam |
Close Mastercam. |
| Alt + F8 |
Configure Mastercam |
Open Systems Configuration. |
| Alt + F9 |
Show Gnomons |
|
| Alt + F12 |
Rotate Position |
Select a center point for motion controller. |
| Alt + G |
Grid Settings |
Opens Grid Settings. |
| Alt + H |
Help |
Opens Mastercam Help. |
| Alt + I |
Solids Manager |
Opens Solids Manager. |
| Alt + L |
Planes Manager |
Opens Plane Manager. |
| Alt + M |
Multi-Threading Manager |
Opens Multi-Threading Manager. |
| Alt + O |
Toolpaths Manager |
Opens Toolpath Manager. |
| Alt + P |
GView – Previous View |
Returns GView to the previous view. |
| Alt + S |
Shading Toggle |
Toggles Shading On / Off. |
| Alt + T |
Show / Hide displayed Toolpaths |
Toggle Toolpaths On / Off. |
| Alt + V |
About Mastercam |
|
| Alt + X |
Set From Entity |
Select an entity to set Main Color, Level, Style, and Width. |
| Alt + Z |
Levels Manager |
Opens Level Manager. |
| Ctrl + A |
Select All |
Select all entities in Graphical window. |
| Ctrl + C |
Copy to Clipboard |
Copy selection to clipboard. |
| Key |
Function |
Description. |
| Ctrl + S |
Save |
Saves file. |
| Ctrl + T |
Shading translucency toggle |
Toggle Translucency on/off. |
| Ctrl + V |
Paste |
Pastes Clipboard contents to the graphical window. |
| Ctrl + X |
Cut to clipboard |
Move selection to clipboard. |
| Ctrl + Y |
Redo |
Redo previous commands with each click. |
| Ctrl + Z |
Undo |
Undo previous commands with each click. |
| Ctrl + Shift + S |
Save As |
Open File Save As dialog. |
| F1 |
Window |
Specify a Zoom Window using the mouse. |
| F2 |
Unzoom Previous 50% |
Unzoom previous view by 50%. |
| F4 |
Analyze Entity |
Select an Entity to Analyze. |
| F5 |
Delete Entities |
Select Entities to Delete. |
| F9 |
Show Axes |
Display X, Y, Z axes. |
| Arrow Keys |
Pan |
Use Arrow keys to Pan the direction of the Graphical view. |
| Pg. Up / Pg. Down |
Zoom /Unzoom by 5% |
Use Pg. Up to Zoom and Pg. Down to Unzoom by 5%. |
