What's New in Verisurf 2019 Webinar On-Demand

Keep your Verisurf skills up to date with this in-depth technical presentation covering the latest improvements now available in Verisurf 2019. Whether you were unable to attend any of the recent "What's New in Verisurf 2019" live webinar sessions or simply want to review the information again, this is a great tool to keep your product knowledge current. Verisurf 2019 introduces extensive, new functionality you can put to work immediately to streamline your inspection, tool building, and reverse engineering work regardless of the types of measurement hardware you use.Go to the Verisurf 2019 web pageWatch the presentation HERE: ...

Read Full Article


New REVERSE Tools Simplify Point Cloud- and Mesh to Solid Model Workflows

Reverse engineering workflows typically include fitting CAD entities to one or more point-cloud meshes. The 2019 release of Verisurf REVERSE includes an improved 2D Slice function that provides finer control when creating 2D geometry using the current screen orientation. The new Export to Edge Splines tool (mesh speed menu) creates closed-edge splines from free mesh edges on the current CAD level. Exported splines can be further edited or otherwise used during the solid modeling process. Watch this video illustration of 2D Mesh Slice and Export to Edge Splines to view a practical, time-saving workflow that takes advantage of these two functions.Watch the 2D Slice and...

Read Full Article


New Master3DGage™ Powered by Verisurf

First Article Inspection and Reporting in MinutesThe Master3DGage development team announced, today, the all New, third generation, Master3DGage – the affordable and portable rapid 3D inspection and reverse engineering solution that enables machine shops to increase efficiency, improve part quality, and reduce scrap. The complete hardware/software solution delivers automated ‘in-process’ inspection right to the shop floor, providing first article inspection and reporting in minutes.  “The New Master3DGage solution continues to close the loop in digital manufacturing workflows,” said Austin Husted, Hardware Product Manager.  “Manuf...

Read Full Article


Quality Inspection Software Platform Improves Departmental Efficiency

B&B Airparts, a Wichita, KS manufacturer offering multiple (horizontal) manufacturing services wanted to grow its business by improving competitiveness against more efficient vertical job shops. After conducting an in-depth needs analysis, they selected Verisurf with Universal CMM as the common software platform that would support both their existing and future inspection hardware systems. The results: a steady 35% annual growth rate. Read the whole B&B Airparts’ case study in the Jan, 2019 issue of Modern Machine Shop here:B&B Airparts Case Study: Modern Machine Shop Magazine Jan '19 Issue ...

Read Full Article


Tech Tip - Measuring Single Point Circles and 2-Point Slots

Tech Tip – Save Time Measuring Hole or Slot Size and LocationIt’s easy to evaluate feature size and location fast in Verisurf by measuring just a single point for holes or 2 points for slots. This technique is ideal for measuring parts or materials with looser tolerances like sheet metal, plastics, and wood. Download the Tech Tip now and learn more about this time-saving method! Tech Tip - Measuring Single Point Circles and 2-Point Slots...

Read Full Article
